神钢零件查询(6D31-T) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (02-009 ) - OIL LINE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
580 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME018182 | [1] | PIPE | KOBPIPE.OIL I/P |
| 2. | VAMH037279 | [1] | BOLT | KOBBOLT,EYE |
| . . | VAMF660063 | [2] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 30. | VAME088315 | [1] | PIPE | KOBPIPE,OIL TURBO INLET |
| 32. | VA3003638302 | [2] | CLAMP CLAMP | CLAMP CLAMP |
| 33A. | VAME920041 | [2] | SPACER | KOBSPACER L=17 |
| 34. | VAMF140229 | [2] | BOLT | KOBBOLT,FLANGE 8X30 |
| 38. | VAMF650102 | [1] | SCREW | KOBBOLT,EYE |
| 39. | VAME088283 | [1] | PIPE | KOBPIPE,OIL TURBO OUTLET |
| 44. | VAME014559 | [2] | GASKET | KOBGASKET Superseded by part number: VAME073842 |
| 45. | VAMH000999 | [2] | BOLT | KOBBOLT,FLANGE 6X12 |
| 46. | VAMF140223 | [2] | BOLT | KOBBOLT,FLANGE 8X16 |
| 47. | VAME014532 | [1] | GASKET | KOBGASKET Superseded by part number: VAME013757 |
