神钢零件查询(6D31-T) - MITSUBISHI DIESEL ENGINE - MD200BLC EXCAVATORS (1/06-12/06) (05-001) - INSTRUMENT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
583 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | VAMH052064 | [1] | TERMINAL | KOBCONNECTOR |
| 2A. | VAMH052002 | [1] | HYD CONNECTOR | KOBCONNECTOR, C8184 |
| 2F. | VA3096803122 | [1] | GROMMET | KOBGROMMET |
| 2G. | VAMH052377 | [1] | HYD CONNECTOR | KOBCONNECTOR, 1P FEMALE |
| 2H. | VAMH052231 | [1] | HYD CONNECTOR | KOBCONNECTOR, 2P FEMALE |
| 2K. | VAMB286874 | [2] | HYD CONNECTOR | KOBCONNECTOR, 2P FEMALE |
| . . | VAMB286874 | [1] | HYD CONNECTOR | KOB |
| 2L. | VAMH052356 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 2M. | VAMH022419 | [1] | GROMMET | KOBGROMMET |
| 3A. | VAMH052042 | [1] | HYD CONNECTOR | KOBCONNECTOR, 6P FEMALE |
| 5A. | VAME049228 | [1] | RELAY, SAFET. MEC | RELAY, SAFET. MEC |
| 7. | VAME067626 | [1] | RELAY | KOBHEATER, MEC Superseded by part number: VAME049306 |
| . . | VAME067637 | [1] | FUSE | KOB164A |
