神钢零件查询(6D31-T) - MITSUBISHI DIESEL ENGINE - MD200BLC EXCAVATORS (1/06-12/06) (03-011) - FUEL RETURN SYSTEM Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
547 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAMS602013 | [5] | FLEXIBLE HOSE | KOBHOSE, FUEL 6 X 110 Superseded by part number: VAMS602013A |
| 2. | VAMS602035 | [1] | HOSE HOSE, FUEL 6 X 220 | HOSE HOSE, FUEL 6 X 220 |
| 3. | VAMS660163 | [13] | CLAMP | KOBCLIP, HOSE 11.6 Superseded by part number: VA0531771160 |
| 4. | VAME019612 | [1] | PIPE B FUEL LEAK OFF | PIPE B FUEL LEAK OFF |
| 5. | VAME016571 | [1] | CAP | KOB |
| 6. | VAMH020801 | [1] | CLIP | KOBCLIP |
| 7. | VAMH000999 | [1] | BOLT | KOBBOLT, FLANGE 6 X 12 |
