神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (01-001) - CYLINDER BLOCK Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
749 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCRANKCASE CF GN450-800A |
| 2. | VAME001245 | [6] | SLEEVE,STD REPAIR SLEEVE, CYL STD | SLEEVE,STD REPAIR SLEEVE, CYL STD |
| 2. | VAME001246 | [1] | SLEEVE, CYL OS 0.5 | |
| 3. | VA3170720800 | [1] | CAP | KOBCAP, SEALING |
| 4. | VAMS666140 | [10] | PLUG | KOBCAP, SEALING 35 |
| 5. | VAMS666137 | [6] | CAP | KOBCAP, SEALING 25 |
| 6. | VAMS666143 | [2] | CAP | KOBCAP, SEALING 50 |
| 7. | VAMF665536 | [2] | SEAL | KOBCAP, SEALING 20 |
| 8. | VAMF540011 | [4] | BALL | KOBBALL, STEEL |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 1 CF GN450-800A |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 2 |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 3 |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 4 |
| 13. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 5 |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 6 |
| 15. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 7 |
| 16. | VAMH012041 | [6] | PIN | KOBPIN, SPG 4X10 |
| 17. | VAMH000315 | [14] | SCREW | KOBBOLT |
| 18. | VA3170720700 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO. 1 |
| 19. | VA3130713201 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO. 2 |
| 20. | VA3130713301 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO. 3 |
| 21. | VA3140713401 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO. 4 |
| 22. | VAMH007010 | [2] | PIN | KOBPIN, DOWEL, FOR F/W HOUSING |
| 23. | VAMH007010 | [1] | PIN | KOBPIN, DOWEL, FOR FR PLATE |
| 24. | VAMF472406 | [1] | PIN | KOBPIN, DOWEL, FOR FR PLATE |
| 25. | VAMF472587 | [2] | PIN | KOBPIN, SPG, FOR CYL HEAD 6X16 |
| 26. | VA3130701801 | [4] | SEAL | KOBSEAL, SIDE Superseded by part number: 77268678, VAME001313 |
| 28. | VAME000024 | [1] | CAP | KOBCAP, SEALING |
| 29-30. | VAME001181 | [1] | FRONT PLATE ASSY | |
| 29. | VAME001182 | [1] | PLATE, FR | |
| 30. | VAMH007010 | [1] | PIN | KOBPIN, DOWEL |
| 31. | VA3130714302 | [1] | GASKET | KOBGASKET,FR,PLATE Superseded by part number: VAME001630 |
| 32. | VAMF140223 | [2] | BOLT | KOBBOLT, FLANGE 8X16 |
| 33. | VAME001195 | [1] | OIL SEAL | KOBOR SLEEVE, CRANKSHAFT (AVAILABLE IN SET WITH ME001196,3130718603) |
| 33. | VAME001196 | [1] | OIL SEAL | KOBOR SLEEVE, CRANKSHAFT (AVAILABLE IN SET WITH ME001196,3130718603) |
| 33. | VA3130718603 | [1] | SLEEVE CYLINDER | KOBOILSEAL OR SLEEVE, CRANKSHAFT (AVAILABLE IN SET WITH ME001196,3130718603) |
| 34. | VA3130715903 | [1] | PLATE WASHER PLATE,WSR | PLATE WASHER PLATE,WSR |
| 35. | VAMF140003 | [6] | BOLT | KOBBOLT, FLANGE 6X12 |
