神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (01-004) - FLYWHEEL HOUSING Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
133 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-4. | VAME008535 | [1] | HOUSING ASSY FLYWHEE | HOUSING ASSY FLYWHEE |
| 1. | VAME008536 | [1] | HOUSING, FLYWHEEL | HOUSING, FLYWHEEL |
| 3. | VA3141201100 | [1] | POINTER | |
| 4. | VAMF200073 | [1] | SCREW 6X8 | |
| . . | VAMF450404 | [1] | WASHER | KOBWASHER, SPG 6 Superseded by part number: 132427A1 |
| 5. | VAME020359 | [1] | PLUG | KOBPLUG, DUST Superseded by part number: VAME609555 |
| 6. | VAMF300845 | [9] | BOLT | KOBBOLT,W/WSR 10X30 |
| 7. | VA3014906400 | [2] | BOLT 10X115 | |
| . . | VAMF450406 | [2] | WASHER | KOBWASHER, SPG 10 |
| 8. | VA3123005900 | [2] | SPACER | SMSPACER L=10 |
