神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (01-013) - TIMING GEAR Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
794 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA3132310100 | [1] | DRIVEN GEAR | KOBGEAR, CRANKSHAFT Z=20 |
| 2. | VA3132311102 | [1] | GEAR | KOBGEAR, CAMSHAFT Z=40 |
| 3. | VAMH005020 | [1] | PLATE | KOBWASHER 44 |
| 6. | VAMH000358 | [1] | BOLT BOLT 10X22 | BOLT BOLT 10X22 |
| 7-8. | VA3132313010 | [1] | RING GEAR | KOBIDLER GEAR ASSY |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR,IDLER Z=45 |
| 8. | VAME020488 | [1] | BUSHING | KOBIDLER |
| 9. | VA3132313500 | [1] | SHAFT,IDLER SHAFT,IDLER (AVAILABLE IN SET KN REF 9,10) | SHAFT,IDLER SHAFT,IDLER (AVAILABLE IN SET KN REF 9,10) |
| 10. | VAMF472569 | [1] | PIN/SPG 5X16 | |
| 11. | VAME020491 | [1] | PLATE THRUST | PLATE THRUST |
| 12. | VA3162303701 | [1] | WASHER | KOBWASHER |
| 13. | VAMF101282 | [1] | BOLT BOLT 10X18 | BOLT BOLT 10X18 |
