纽荷兰零件查询(D125C WT/LGP) - CRAWLER DOZER - TIER 4A (10/13-) (50.104.AB[01]) - AIR CONDITIONING, CAB FILTER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
568 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47623210 | [1] | BRACKET | BURCab Air Filter Mount |
| 2. | 47623205 | [1] | GUARD | BURFilter, NH |
| 3. | 47640599 | [1] | SEAL | BUREdge Guard |
| 4. | 87655046 | [4] | SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk | BUR |
| 5. | 604-10030 | [4] | BOLT | BRR |
| 6. | 86624176 | [4] | WASHER,11mm ID x 20mm OD x 2mm Thk | FOR Superseded by part number: 14496621 |
| 7. | 9515003 | [4] | BOLT,Hex, M10 x 1.5 x 30mm, Cl 10.9 | BHB |
| 8. | 9804276 | [2] | FLANGE NUT,M6 x 1.0, Cl 8 | NH |
| 9. | 9671714 | [4] | FLANGE BOLT,Hex, M8 x 1.25 x 25mm, CL 8.8 | NH |
| 10. | 47592869 | [1] | SEAL | BURFliter Close-Off |
| 11. | 47592798 | [1] | PLATE | BURFilter Close-Off |
| 12. | 47592781 | [1] | SEAL | BURCab Air Plate |
| 13. | 47601625 | [1] | PANEL | BURCab Air Intake, Painted |
| 14. | L11541 | [1] | CABLE TIE,203.2mm L, Nylon | CAS Superseded by part number: 87000312 |
