纽荷兰零件查询(D125C WT/LGP) - CRAWLER DOZER - TIER 4A (10/13-) (50.104.AB[02]) - CAB, AIR FILTER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
503 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47658394 | [1] | AIR FILTER | BURHousing Assembly Incl 9 And 10 |
| 2. | 47658398 | [1] | HOSE | BUR |
| 3. | 87525506 | [2] | CLAMP,3.75" - 4.62", Worm Gear | FAR |
| 4. | 84277200 | [1] | ELEC CONNECTOR | BUR |
| 5. | 47608024 | [2] | PLATE | BUR |
| 6. | 87035448 | [8] | SPACER,8.48mm ID x 12.7mm OD x 12.7mm L | CAS |
| 7. | 84543948 | [16] | FLANGE BOLT | BUR |
| 8. | 86625061 | [16] | NUT,1/4"-20, GB | SAS |
| 9. | 47658397 | [1] | ELECTRIC MOTOR | BURInternal Fan, Incl In Ref. 1 |
| 10. | 47658396 | [1] | FILTER | BURElement, Incl In Ref. 1 |
