神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (02-004) - FAN AND PULLEY Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
249 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME008230 | [1] | FAN | KOBPUSHER TYPE PPG D=540 |
| 2. | VAME019202 | [1] | SPACER L=60 | |
| 3. | VA3164500200 | [1] | PULLEY | KOBPULLEY, WATER PUMP PCD130 |
| 4. | VA3164881400 | [1] | PLATE, WSR | |
| 5. | VAMF241282 | [4] | BOLT | KOBBOLT, W/WSR 10X25 |
| 6. | VAMF241266 | [4] | BOLT | KOBBOLT, W/WSR 8X65 |
| 8. | VA3174890000 | [1] | BELT, TRANSMISSION | KOBV-BELT B L=1105 (FOR M3 ONLY) |
| . . | VAME900744 | [1] | BELT, TRANSMISSION | KOBV-BELT B L=1140 (FOR M5 ONLY) |
