神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (02-005) - OIL PUMP AND GEAR TRAIN Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
500 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-15. | VAME008142 | [1] | ENGINE OIL PUMP | KOBOIL PUMP ASSY |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCASE, OIL PUMP |
| 2. | V3173590400 | [1] | COVER, OIL PUMP | |
| 3. | VAMF241227 | [4] | BOLT | KOBBOLT, W/WSR 6X20 |
| 4. | VA3173510090 | [1] | SHAFT | KOBOIL PUMP SHAFT ASSY |
| 6. | VA3133503100 | [1] | GEAR,PUMP DRIVE GEAR, PUMP DRIVE | GEAR,PUMP DRIVE GEAR, PUMP DRIVE |
| 9. | VA3133503200 | [1] | PIN | |
| 10. | VA3173692400 | [1] | GASKET GASKET | GASKET GASKET |
| 11. | VAME008143 | [1] | STRAINER,OIL STRAINER,OIL | STRAINER,OIL STRAINER,OIL |
| 14. | VA3143616200 | [1] | STAY | |
| 15. | VAMF244850 | [1] | B0LT, W/WSR 8X18 | |
| 18. | VAMF244850 | [1] | BOLT, W/WSR 8X18 | |
| 20. | VAMH037233 | [1] | BOLT BOLT, JOINT | BOLT BOLT, JOINT |
| 21. | VAMF660068 | [1] | PACKING | KOBGASKET 20 Superseded by part number: VAF420220000 |
| 22. | VA3133514600 | [1] | NUT, CAP | |
