神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (04-004) - ALTERNATOR (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
675 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-26B. | VAME067616 | [1] | ALTERNATOR ASSY 24V-40A (INNER PARTS) (MEC A004T57476) | ALTERNATOR ASSY 24V-40A (INNER PARTS) (MEC A004T57476) |
| 1. | A529X05471 | [1] | NUT SET (ME700141) | |
| 2. | A628T36171 | [1] | PULLEY ASSY BX1 (ME700231) | |
| 3. | A414X14971 | [1] | SCREW SET (MM502365) | |
| 4-6. | A640T28070 | [1] | BRACKET ASSY FR (ME700536) | |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET FR |
| 5. | A414X15071 | [1] | SCREW SET (ME700144) | |
| 6. | S930P37201 | [1] | BEARING, FR #6305 (ME700535) | |
| 7-8. | A880T22570 | [1] | ROTOR ASSY (ME700164) | |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONROTOR |
| 8. | S930P33970 | [1] | BEARING, RE #6303 (M0602352) | |
| 13. | A383T20670 | [1] | STATOR (ME700159) | |
| 14-19. | A641T35270 | [1] | BRACKET ASSY RE (ME700165) | |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET, RE |
| 15A. | A450X10571 | [1] | TERMINAL SET (ME700087) | |
| 16. | A771S01017 | [1] | MOLD (MD602826) | |
| 16A. | A308D01601 | [1] | CONNECTION (ME700161) | |
| 16B. | S054S05083 | [1] | SCREW, P 5X8 (MD602674) | |
| 17. | A414X17071 | [1] | SCREW SET (ME700088) | |
| 19. | A860T07570 | [1] | RECIFIER RECTIFIER ASSY (ME700167) | RECIFIER RECTIFIER ASSY (ME700167) |
| 20-22. | A866X03170 | [1] | REGULATOR ASSY (ME700228) | |
| 20. | NSS | [1] | NOT SOLD SEPARAT | CONREGULATOR |
| 21. | A648D01971 | [2] | COMMUTATOR BRUSH | KOBBRUSH (MM502377) |
| 22. | A389D01901 | [2] | SPRING, BRUSH (MM502378) | |
| 26. | A212C11101 | [1] | COVER (ME700163) | |
| . . | S183S05124 | [1] | BOLT, W/WSR 5X12 (ME700100) | |
| 26B. | A981S60102 | [2] | BOLT, W/WSR 6X12 (ME700154) | |
