神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (04-005) - ALTERNATOR (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
850 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-27. | VAME049158 | [1] | DYNAMO ALTERNATOR ASSY 24V-25A (INNER PARTS) (MEC A002T71683) | DYNAMO ALTERNATOR ASSY 24V-25A (INNER PARTS) (MEC A002T71683) |
| 1. | A529X04971 | [1] | NUT SET (MM502363) | |
| 2. | A628T40071 | [1] | PULLEY ASSY BX1 (ME700359) | |
| 3. | A414X14971 | [1] | SCREW SET (MM502365) | |
| 4-6. | A640T24670 | [1] | BRACKET ASSY FR (ME700351) | |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET, FR |
| 5. | A414X10071 | [1] | SCREW SET (MM502229) | |
| 6. | S930P33970 | [1] | BEARING, FR (M0602352) | |
| 7-8. | A880X21870 | [1] | ROTOR SET (ME700084) | |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONROTOR |
| 8. | S930P36070 | [1] | BEARING, RE (M0607200) | |
| 13. | A383T20270 | [1] | STATOR (ME700085) | |
| 14-19. | A641T42470 | [1] | BRACKET ASSY RE (ME700360) | |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET, RE |
| 15A. | A450X10571 | [1] | TERMINAL SET (ME700087) | |
| 16. | A771S01017 | [1] | MOLD (MD602826) | |
| 16A. | A308D02501 | [1] | CONNECTION (ME700357) | |
| 16B. | S054S05083 | [1] | SCREW, P 5X8 (MD602674) | |
| 17. | A414X17071 | [1] | SCREW SET (ME700088) | |
| 19. | A860T06870 | [1] | RECTIFIER (ME700168) | |
| 20-22. | A866X01070 | [1] | REGULATOR SET (ME700091) | |
| 20. | NSS | [1] | NOT SOLD SEPARAT | CONREGULATOR |
| 21. | A6A8D01971 | [2] | BRUSH (MM502377) | |
| 22. | A389D01901 | [2] | SPRING, BRUSH (MM502378) | |
| 26. | A210X91471 | [1] | COVER (ME700329) | |
| 27. | A210X91671 | [1] | COVER SET (ME700358) | |
