神钢零件查询(6DR5) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (08-001) - CYLINDER BLOCK REPAIR KIT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
687 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-32. | VAME999261 | [1] | CRANK CASE ASSY | CRANK CASE ASSY |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCRANKCASE (ME001164) |
| 2. | VAME001245 | [6] | SLEEVE,STD REPAIR STD | SLEEVE,STD REPAIR STD |
| 3. | VA3170720800 | [1] | CAP | KOBCAP, SEALING |
| 4. | VAMS666140 | [10] | PLUG | KOBCAP, SEALING 35 |
| 5. | VAMS666137 | [6] | CAP | KOBCAP, SEALING 25 |
| 6. | VAMS666143 | [2] | CAP | KOBCAP, SEALING 50 |
| 7. | VAMF665536 | [2] | SEAL | KOBCAP, SEALING 20 |
| 8. | VAMF540011 | [4] | BALL | KOBBALL, STEEL |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 1 (3130711102) |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 2 (3130711201) |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 3 (3130711301) |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 4 (3140711401) |
| 13. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 5 (3140711501) |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 6 (3140711601) |
| 15. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG NO. 7 (3140711702) |
| 16. | VAMH012041 | [6] | PIN | KOBPIN, SPG 4X10 |
| 17. | VAMH000315 | [14] | SCREW | KOBBOLT |
| 18. | VA3170720700 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO. 1 |
| 19. | VA3130713201 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO. 2 |
| 20. | VA3130713301 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO. 3 |
| 21. | VA3140713401 | [1] | BUSHING | KOBBUSHING, CAMSHAFT NO. 4 |
| 22. | VAMH007010 | [2] | PIN | KOBPIN, DOWEL 12 |
| 23. | VAMH007010 | [1] | PIN | KOBPIN, DOWEL |
| 24. | VAMF472406 | [1] | PIN | KOBPIN, DOWEL |
| 25. | VAMF472587 | [2] | PIN | KOBPIN, SPG 6X16 |
| 26. | VA3130701801 | [4] | SEAL | KOBSEAL, SIDE Superseded by part number: 77268678, VAME001313 |
| 28. | VAME000024 | [1] | CAP | KOBSEALING |
| 29. | VAMH037237 | [6] | PLUG | KOBPLUG, TAPER PT1/8 |
| 30. | VAME040252 | [1] | HANGER | SMHANGER, RE |
| 31. | VA3160707501 | [1] | HANGER, FR | |
| 32. | VAMF300866 | [2] | BOLT BOLT, W/WSR 12X25 | BOLT BOLT, W/WSR 12X25 |
