| 1. | 47672724 | [1] | DIESEL EXHAUST FLUID TANK | BUR |
| 2. | 87655046 | [4] | SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk | BUR |
| 3. | 412151 | [4] | BOLT,M10 x 1.5 x 61.58mm, Cl 8.8 | NH Superseded by part number: 73161469 |
| 4. | 84395621 | [1] | BRACKET | BUR |
| 5. | 47512698 | [1] | SENSOR | BRR |
| 6. | 614-6020 | [3] | BOLT,Hex, M6 x 1 x 20mm, Cl 8.8, Full Thd | CAS Superseded by part number: 120100 |
| 7. | 84151635 | [1] | HEATER VALVE | GI |
| 8. | 87655042 | [6] | SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk | BUR |
| 9. | 120062 | [3] | BOLT,Hex, M8 x 70mm, Cl 8.8 | NH Superseded by part number: 7120024 |
| 10. | 9706690 | [3] | NUT,M8 x 1.25, Cl 8 | NH Superseded by part number: 43362 |
| 11. | 47364111 | [1] | ECU | BURFor Module Filter See Callout 45 |
| 12. | 434177A1 | [4] | ISOLATOR | CAS Superseded by part number: 86630020 |
| 13. | 87528983 | [8] | WASHER,8.4mm ID x 25mm OD x 2mm Thk | BN |
| 14. | 412479 | [4] | BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8 | NH |
| 15. | 47735815 | [1] | NIPPLE,1/2 STR NPTF TO M18X1.5 | BUR |
| 16. | 84422753 | [1] | SHUT-OFF VALVE,1/2" NPT x 1/2" NPT | BUR |
| 17. | 84422999 | [2] | FITTING | BUR |
| 18. | 47508268 | [1] | HOSE,12.7mm ID x 1776mm L, SAE 20R3 | BUR |
| 19. | 87487830 | [2] | CLAMP,0.81" - 1.75" | BRR |
| 20. | 84423014 | [1] | CAP,1/2" - 14 | BUR |
| 21. | 87530629 | [2] | CLAMP,20.6mm, Coat, 11.9mm Bolt Hole, P Type | BUR |
| 22. | 87032428 | [1] | CLAMP,22.2mm, Coat, 10.3mm Bolt Hole, J Type | BRR |
| 23. | 43138 | [5] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8 | NH |
| 24. | 84387525 | [1] | HOSE ASSY. | BURFor In Line Filter See Callout 44 |
| 25. | 84465538 | [1] | HOSE ASSY. | BUR |
| 26. | 84527816 | [3] | HOSE,9.5mm ID x 100mm L | BUR |
| 27. | 214-1706 | [6] | HOSE CLAMP,#06, 0.44" - 0.78", Type M Worm | CAS Superseded by part number: 86625041 |
| 28. | 86566990 | [2] | CABLE TIE,292mm OAL x 4.8mm W | ZED |
| 29. | 86625228 | [1] | HYD CONNECTOR | WIC |
| 30. | 43140 | [5] | BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8 | NH |
| 31. | 515-23143 | [1] | CLAMP,9/16", Insul, 3/8" Bolt | CAS Superseded by part number: 72187280, 257492 |
| 32. | 217-380 | [1] | FITTING,3/8" Hose X 3/8" NPTF Beaded | CAS Superseded by part number: 86625229 |
| 33. | 87573373 | [4] | CLAMP,33.3mm, Coat, 10.3mm Bolt Hole, P Type | GI |
| 34. | 87301688 | [2] | CLAMP,41.2mm, Coat, P Type | GI |
| 35. | 84574719 | [1] | BRACKET | BUR |
| 36. | 84574721 | [1] | HOSE | BUR |
| 37. | 84315307 | [1] | FILLER | FAR |
| 38. | 87483158 | [1] | NECK FILLER | RAC |
| 39. | 84246766 | [4] | HEX SOC SCREW,M4 x 12mm, SST | BN |
| 40. | 84206552 | [1] | FILLER CAP | BAS |
| 41. | L115548 | [2] | CLAMP,57.15mm - 79.38mm | CAS |
| 42. | 393392 | [3] | LOCK NUT,M6 x 1.0, Cl 8 | WIN Superseded by part number: V43393 |
| 43. | 495-11028 | [3] | WASHER,1/4", SAE | CAS Superseded by part number: 87361, 72187256 |
| 44. | 84153651 | [1] | FILTER SCREEN | FAR100 Micron Tank to Supply Module |
| 45. | 84254852 | [1] | FILTER | BAS10 Micron Supply Module |
