纽荷兰零件查询(D180C LT) - CRAWLER DOZER - TIER 4A (12/13-) (29.218.AC[01]) - HYDROSTATIC TRANSMISSION New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
537 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 201-106 | [1] | HYD CONNECTOR,11/16"-16 ORFS x 3/4"-16 ORB | CAS Superseded by part number: 87672176 |
| 2. | 9840325 | [2] | HYD CONNECTOR,1 11/16"-12 ORFS x 1 5/8"-12 ORB | WIN |
| 3. | 9840542 | [4] | ELBOW,90º, 9/16"-18 x 9/16"-18, Adj, ORFS | BAS |
| 4. | 9846955 | [1] | 90 ELBOW | GI90 ADJ 1.0 ORFS - ORB 1.0 |
| 5. | 47366244 | [1] | HYDRAULIC PUMP | BUR145CC |
| 6. | 47397561 | [1] | HYDRAULIC HOSE,25.4mm ID x 700mm L, SAE 100R16 | BURPump FA and FE |
| 7. | 9843590 | [6] | BOLT,Hex, M20 x 2.5 x 50mm, Cl 10.9, Full Thd | WIN |
| 8. | 47479903 | [1] | STOP | BURFlexible Coupler |
| 9. | 43233 | [3] | BOLT,Hex, M10 x 1.25 x 20mm, Cl 8.8, Full Thd | NH |
| 10. | 88685 | [1] | BOLT,Hex, 5/8" x 1 1/2", Gr 8, Full Thd | ZED |
| 11. | 47569456 | [1] | PLATE | BURMount |
| 12. | 84238740 | [1] | FITTING | BHBTee, ORFS ADJ STR THD RUN 1.0 |
| 13. | 84390792 | [1] | 90 ELBOW | BU90 ADJ Jump 3/8 ORFS - ORB 1/2 |
| 14. | 86624156 | [1] | WASHER,0.66" ID x 1.5" OD x 0.19" Thk | FOR |
| 15. | 87655042 | [3] | SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk | BUR |
| 16. | 87675522 | [1] | ELBOW | BRR90 ADJ 5/8 ORFS - ORB 5/8 |
| 17. | 87713134 | [6] | SPECIAL WASHER | BUR21.25 x 38.1 x 4.2mm |
