| 1. | 214-2130 | [1] | CLAMP,#30, 1.81"-2.06", T-Bolt | CAS Superseded by part number: 71404506 |
| 2. | 214-2148 | [1] | CLAMP,#48, 2.37"-2.68", T-Bolt | CAS |
| 3. | 43127 | [2] | BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8 | NH |
| 4. | 43139 | [3] | BOLT,M10 x 1.5 x 25mm, Cl 8.8 | NH Superseded by part number: 11106231, 11106231, BER43139 |
| 5. | 84674 | [1] | HOSE CLAMP,33.3mm - 57.1mm | WIN |
| 6. | 437013 | [1] | NUT | BHB Superseded by part number: 9804277 |
| 7. | 9840589 | [2] | O-RING,0.07" Thk x 1.489" ID, -29, Cl 6, 90 Duro | WIN |
| 8. | 9846955 | [2] | 90 ELBOW | GI |
| 9. | 47390274 | [1] | TUBE | BURManifold to Cooler |
| 10. | 47395555 | [1] | HYDRAULIC HOSE,38mm ID x 2162mm L, SAE 100R4 | BURCooler to Manifold |
| 11. | 47395616 | [1] | BRACKET | BURTube Support |
| 12. | 47480703 | [1] | HOSE,50.8mm ID x 735mm L, SAE 100R4 | BURCharge Suction |
| 13. | 47512131 | [1] | HOSE,38.1mm ID x 1315mm L, SAE 100R4 | BURManifold to Tank |
| 14. | 47512132 | [1] | HOSE,38.1mm ID x 1425mm L, SAE 100R4 | BURManifold to Cooler |
| 15. | 47634777 | [1] | CLAMP | BHBClosed 50.8mm |
| 16. | 84485209 | [1] | HYD. TUBE | BURFilter to Pump |
| 17. | 84485212 | [1] | HYD. TUBE | BURPump FE to Filter |
| 18. | 84989392 | [2] | ELBOW,90º, 11/16"-16 ORFS x 11/16"-16 Fem Sw | ZED |
| 19. | 86634098 | [1] | FITTING,1 1/2" Hose x 1 7/8"-12 ORB, Beaded | RAC |
| 20. | 86639006 | [2] | CLAMP,38.1mm, Coat, 13.5mm Bolt Hole, P Type | FAR |
| 21. | 87573379 | [2] | CLAMP,57.1mm, Coat, 13.5mm Bolt Hole, P Type | GI |
| 22. | 87655042 | [3] | SPECIAL WASHER,8.8mm ID x 17.5mm OD x 2.2mm Thk | BUR |
| 23. | 87655046 | [2] | SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk | BUR |
| 24. | 87687101 | [1] | WASHER,10.65mm ID x 31mm OD x 3.3mm Thk | IMO |
| 25. | D40236 | [1] | CLAMP | CAS |
