卡特零件查询（725C） 441-8503: LAMP GP-PAYLOAD SIGNAL
广数供应链运营团队, 14 02月, 2025，浏览：
200 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 3S-2093 | [8] | STRAP-CABLE | |
| 2. | 441-8504 | [1] | BRACKET | |
| 3. | 453-1895 | [1] | PLATE AS | |
| | 8T-3490M | [2] | NUT-WELD(M10X1.5-THD) | |
| | 8T-3612M | [2] | NUT-WELD(M8X1.25-THD) | |
| 4. | 480-3070Y | [1] | LAMP GP-SIGNAL | |
| 5. | 480-3071Y | [1] | HARNESS AS-MONITOR(PAYLOAD) | |
| 6. | 104-3987 | [1] | CLIP | |
| 7. | 338-8439 | [2] | CLIP | |
| 8. | 344-5675M | [1] | NUT(M10X1.5-THD) | |
| 9. | 8K-1433 | [1] | GROMMET | |
| 10. | 8T-4121 | [5] | WASHER-HARD(11X21X2.5-MM THK) | |
| 11. | 8T-4137M | [2] | BOLT(M10X1.5X20-MM) | |
| 12. | 8T-4186M | [1] | BOLT(M10X1.5X40-MM) | |
| 13. | 8T-4189M | [2] | BOLT(M8X1.25X20-MM) | |
| 14. | 8T-4195M | [1] | BOLT(M10X1.5X30-MM) | |
| 15. | 8T-4224 | [3] | WASHER-HARD(8.8X16X2-MM THK) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
