久保田零件查询D01700 HST3 (MOTOR) [COMPONENT PARTS] TRANSMISSIONEPC Kubota online
广数供应链运营团队, 14 02月, 2025，浏览：
270 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 010. |
6C54011607
|
[1] |
HST,ASSY(T-21,D32)
|
42.5040(lbs); 19.320
|
| 020. |
6A11035240
|
[1] |
COLLAR,THRUST(24X10)
|
0.0044(lbs); 0.002
|
| 030. |
6A11035122
|
[1] |
BEARING,NEEDLE
|
0.0506(lbs); 0.023
|
| 040. |
6E11011810
|
[1] |
SHAFT
|
0.9284(lbs); 0.422
|
| 050. |
K316111402
|
[1] |
ASSY CYLINDER
|
2.1340(lbs); 0.970
|
| 060. |
5H55019280
|
[1] |
CIR CLIP,EXTERNAL
|
0.0044(lbs); 0.002
|
| 070. |
5H55019250
|
[1] |
SPRING
|
0.0308(lbs); 0.014
|
| 080. |
K771114220
|
[1] |
BEARING,THRUST BALL
|
0.4840(lbs); 0.220
|
