纽荷兰零件查询(D180C LT) - CRAWLER DOZER - TIER 4A (12/13-) (90.160.AB[01]) - POST, COVER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
977 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 844-8020 | [2] | BOLT,Hvy Hex, M8 x 20mm, Cl 8.8 | CAS Superseded by part number: 9804258 |
| 2. | 84172340 | [4] | BUMPER | BUR |
| 3. | 84378818 | [1] | COVER | BUR |
| 4. | 84378819 | [1] | COVER | BUR |
| 5. | 84378820 | [1] | TRIM PANEL,69.1mm W x 854mm L x 8mm Thk | BUR |
| 6. | 84378822 | [1] | COVER | BUR |
| 7. | 87551002 | [4] | SCREW,M3.5 x 26.40mm | BUR |
| 8. | 87691835 | [2] | LOUVER | BUR |
| 9. | 182697A1 | [12] | FASTENER | CAS |
