纽荷兰零件查询(D180C LT) - CRAWLER DOZER - TIER 4A (12/13-) (90.160.AF[01]) - CAB INTERIOR TRIM New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
230 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 353-429 | [4] | PLUG | CAS Superseded by part number: 86625134 |
| 2. | 614-8025 | [4] | BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd | CAS Superseded by part number: 43127 |
| 3. | 896-11008 | [4] | WASHER,9mm ID x 17mm OD x 2mm Thk | CAS Superseded by part number: 86624185 |
| 4. | 13276217 | [8] | SCREW,Pozidriv Pan Hd, M6 x 16mm, Cl 5.8, Full Thd | IMO |
| 5. | 84559979 | [2] | ANGLE | BURFloor Mat Retainer |
| 6. | 47472012 | [1] | ACCESS COVER | BURFront Console Harness |
| 7. | 84594255 | [2] | FOOTREST | BUR |
| 8. | 84196923 | [1] | ANTI-SKID STRIP | BURBulk Cut To Lenght 425mm |
| 9. | 84601079 | [1] | FLOOR MAT | BURSmall Cab |
| 10. | 84601082 | [1] | RUBBER STRIP | BURBacked Hole 64mm |
| 11. | 87448669 | [1] | SEAL | RACAdhesive Backed Hole 64mm |
| 12. | 87605321 | [2] | SPACER,6.8mm ID x 10.3mm OD x 6.4mm L | BN1/8 Pipe 0.25" Snd |
| 13. | 198820C1 | [1] | GROMMET | IH Superseded by part number: 86976972 |
| 14. | 47521860 | [4] | PLUG | BURRubber M16 |
| 15. | 47518387 | [1] | FOAM | BURLower Front Harness |
