卡特零件查询（725C） 391-4127: WIRING GP-ENGINE
广数供应链运营团队, 14 02月, 2025，浏览：
562 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 394-3902 | [1] | CONTROL GP-ENGINE ELECTRONIC | |
| 2. | 373-3653 | [1] | PLATE AS | |
| | 159-9540M | [4] | NUT-WELD(M8X1.25-THD) | |
| 3. | 388-8815Y | [1] | HARNESS AS-CAB | |
| 4. | 392-8993 | [1] | BRACKET | |
| 5. | 237-9960 | [2] | CLIP(LADDER) | |
| 6. | 5P-4116 | [4] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 7. | 6I-1418 | [4] | SPACER(8.2X12.7X28.7-MM THK) | |
| 8. | 7K-1181 | [8] | STRAP-CABLE | |
| 9. | 7X-0818M | [2] | BOLT(M8X1.25X45-MM) | |
| 10. | 8T-4121 | [6] | WASHER-HARD(11X21X2.5-MM THK) | |
| 11. | 8T-4137M | [6] | BOLT(M10X1.5X20-MM) | |
| 12. | 8T-4171M | [2] | BOLT(M6X1X12-MM) | |
| 13. | 8T-6912M | [2] | BOLT(M8X1.25X50-MM) | |
| 14. | 8T-9655 | [8] | MOUNT-ISOLATION | |
| 15. | 9X-8256 | [2] | WASHER(6.6X12X2-MM THK) | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
