纽荷兰零件查询(D180C WT/LGP) - CRAWLER DOZER - TIER 4A (12/13-) (86.110.AD[01]) - BLADE SEMI - U New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
703 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47608925 | [1] | DOZER BLADE | BURIncl 2 - 12 Superseded by part number: 47727962 |
| 2. | 84121492 | [1] | CUTTING EDGE,301.5 OAL / 235MM WIDE | BURLateral Sharp, RH |
| 3. | 84121493 | [1] | CUTTING EDGE,301.5 OAL / 235MM WIDE | BURLateral Sharp, LH |
| 4. | 84121494 | [1] | CUTTING EDGE,326.8 MM OAL / 200MM WIDE | BURLateral Sharp, Inner, LH |
| 5. | 84121491 | [1] | CUTTING EDGE,326.8 OAL / 200MM WIDE | BURLateral Sharp, Inner, RH |
| 6. | 8282270 | [16] | PLOW BOLT,Plow, M20 x 1.5 x 67mm, Cl 10.9 | LEC |
| 7. | 895-11020 | [30] | WASHER,M20 x 37 x 3 | CAS Superseded by part number: 140021 |
| 8. | 86015195 | [30] | NUT,M20 x 1.5, Cl 10 | RAC |
| 9. | 8273211 | [14] | PLOW BOLT,Plow, M20 x 1.5 x 62mm, Cl 10.9 | LEC |
| 10. | 86508583 | [12] | BOLT,Hex, M16 x 35mm, Cl 8.8, Full Thd | NH Superseded by part number: 86529976 |
| 11. | 9706704 | [2] | BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8 | NH |
| 12. | NSS | [2] | NOT SERVICED SEPARATELY | CONCenter Plate, Sharp, Included W/ Ref 1 |
