斗山零件查询BREATHER PIPE DX350LC Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
453 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 10. |
65.01801-5100
|
[1] |
. HOUSING;BREATHER
|
|
| 100. |
06.16731-2108
|
[2] |
WASHER;SPRING
|
|
| 110. |
06.11063-8215
|
[2] |
NUT;HEX. M10
|
|
| 120. |
65.96301-0460
|
[1] |
HOSE;RUBBER
|
|
| 130. |
06.67020-0105
|
[2] |
CLAMP
|
|
| 140. |
65.96301-0461
|
[1] |
HOSE;RUBBER
|
|
| 150. |
06.67020-0105
|
[1] |
CLAMP
|
|
| 160. |
65.97460-0002
|
[1] |
CABLE TIE
|
|
| 170. |
65.96301-0438
|
[1] |
HOSE;RUBBER
|
|
| 180. |
06.67020-0105
|
[1] |
CLAMP
|
|
| 190. |
65.90201-0122
|
[1] |
BOLT;STUD
|
|
| 20. |
06.01923-3114
|
[4] |
BOLT ASS`Y M8X22
|
|
| 200. |
65.97401-5019
|
[1] |
CLIP;PIPE
|
|
| 210. |
06.16731-2107
|
[1] |
WASHER
|
|
| 220. |
06.11063-8214
|
[1] |
. NUT
|
|
| 30. |
65.96301-0459
|
[1] |
HOSE;RUBBER
|
|
| 40. |
06.67020-0101
|
[2] |
CLAMP;HOSE
|
|
| 50. |
65.98131-0097
|
[1] |
ADAPTER
|
|
| 60. |
06.56190-0706
|
[1] |
SEAL RING
|
|
| 70. |
65.01840-5003A
|
[1] |
BRACKET;BREATHER PIPE
|
|
| 80. |
06.01913-3117
|
[4] |
BOLT ASS`Y M8X30
|
|
| 90. |
65.01802-5034A
|
[1] |
PIPE;BREATHER
|
|
