凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (31.220.AL[01]) - VAR - 726527, 726528 - REGULAR DUTY IMPLEMENT PTO - STANDARD PICK-UP - COMER GEARBOX Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
681 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87391830
|
[1] |
GEARBOX
|
PA
540 RPM
|
| 1. |
87391830R
|
[1] |
REMAN-GEARBOX
|
PA
540 RPM
|
| 1. |
87391830C
|
[1] |
CORE-GEARBOX
|
PA
Return Number
|
| 1. |
87344585
|
[1] |
GEARBOX
|
PA
1000 RPM
|
| 1. |
87344585R
|
[1] |
REMAN-PTO GEARBOX A.
|
PA
1000 RPM
|
| 1. |
87344585C
|
[1] |
CORE-PTO GEARBOX A.
|
PA
Return Number
|
| 2. |
84253263
|
[1] |
PTO
|
PLO
Slip Clutch, 1450 N-m Superseded by part number: 84253264
|
| 2. |
84358413
|
[1] |
PTO
|
NH
Cut Out Clutch, 1700 N-m
|
| 2. |
84253256
|
[1] |
PTO
|
PLO
Slip Clutch, 1000 N-m
|
| 3. |
87661924
|
[1] |
SPLINED COUPLING
|
PLO
Incl 9 - 11
|
| 4. |
86604822
|
[1] |
SHAFT
|
NH
|
| 5. |
86626270
|
[1] |
DIPSTICK,129mm L
|
NH
|
| 6. |
86979179
|
[1] |
WASHER,16.67mm ID x 34.93mm OD x 6.35mm Thk
|
NH
|
| 7. |
9804271
|
[1] |
BOLT,Hex, M16 x 40mm, Cl 8.8, Full Thd
|
NH
|
| 8. |
86637396
|
[1] |
WASHER,25.6mm ID x 35.3mm OD x 1mm Thk
|
NH
|
| 9. |
300643
|
[2] |
SNAP RING,M38, Int
|
NH
Superseded by part number: 11059776
|
| 10. |
62161
|
[2] |
LUBE NIPPLE,M8 x 1.25, Str
|
NH
|
| 11. |
86637370
|
[2] |
SEAL,40mm ID x 52mm OD x 7mm Thk
|
NH
|
