凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (35.540.AA[03]) - BALE TENSION HYDRAULIC CYLINDER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
165 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87347262
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 25.4mm Rod, 685.8mm Stroke
|
PA
Hydraulic, Bale Tension, RH Superseded by part number: 87347263
|
| 1. |
87517401
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 25.4mm Rod, 685.8mm Stroke
|
PA
Hydraulic, Bale Tension, LH
|
| 2. |
9602227
|
[1] |
LOCK NUT,5/8"-18, GC
|
NH
Superseded by part number: 232-46410
|
| 3. |
9992069
|
[2] |
O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro
|
GI
|
| 4. |
87026541
|
[2] |
ROD
|
PA
Superseded by part number: 47583115
|
| 5. |
87026540
|
[2] |
PISTON,50.37mm Bore, 18.37mm Rod, 31.75mm W
|
PA
|
| 6. |
771705
|
[2] |
RING
|
NH
Wear, 2.004" ID x .50" Thick
|
| 7. |
86553483
|
[2] |
SEAL
|
NH
Piston, 3 Piece
|
| 8. |
87026539
|
[2] |
HEAD
|
PA
|
| 9. |
9616363
|
[2] |
SEAL,25.4mm ID x 31.5mm OD x 6.35mm Thk
|
NH
Seal
|
| 10. |
121189
|
[2] |
OIL SEAL
|
NH
Wiper, 1-1/4" OD x 1/8" Thick
|
| 13. |
511297
|
[2] |
SEAL,41.22mm ID x 50.8mm OD x 1.93mm Thk
|
NH
Backup, 1.638" ID x .064" Thick
|
| 14. |
NSS
|
[2] |
NOT SOLD SEPARAT
|
CON
1.6" ID x .210" Thk
|
| 15. |
87028081
|
[2] |
SEAL KIT
|
PA
|
