凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (35.540.AI[01]) - VAR - 726813 - HYDRAULIC BALE TENSION, DUAL CYLINDERS, MANUAL CONTROL, BETWEEN, YFN188619 AND YGN193202 AND AFTER Case Agriculture_凯斯Case_工程机械

凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (35.540.AI[01]) - VAR - 726813 - HYDRAULIC BALE TENSION, DUAL CYLINDERS, MANUAL CONTROL, BETWEEN, YFN188619 AND YGN193202 AND AFTER Case Agriculture

广数供应链运营团队, 14 02月, 2025，浏览： 168 次

Pos.	Part No	Qty	Parts name	Comments
1.	47794184	[1]	HYDRAULIC CYLINDER	PLO LH, Serial Range: -YGN193202
1.	47860096	[1]	HYDRAULIC CYLINDER	PLO LH, Start Serial: YGN193203
2.	574342	[1]	CAP,9/16" - 18 JIC	LEC
3.	84563524	[1]	HYDRAULIC HOSE	NH 154"
4.	84563525	[1]	HYDRAULIC HOSE	NH 173"
5.	84563528	[1]	HYDRAULIC HOSE,6.3mm ID x 2794mm L, SAE 100R17	NH 110"
6.	76350	[2]	HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC	NH Incl 18
7.	47482891	[1]	HYDRAULIC MANIFOLD	NH Incl 19 - 22, Serial Range: -YGN193202
8.	84549526	[1]	HYDRAULIC CYLINDER	NH RH, Start Serial: YGN193203
8.	47860094	[1]	HYDRAULIC CYLINDER	PLO
9.	84552131	[1]	HYD TUBE	NH Incl 23, 24
10.	86505972	[2]	BOLT,5/16" - 18 x 2 - 1/4", Gr 5	BAS
11.	86513020	[2]	TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC	BEL Incl 18
12.	163335	[1]	TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC	BEL Incl 18
13.	80681	[2]	LOCK NUT,5/16"	NH Superseded by part number: 83990583
14.	86513049	[1]	PLUG,9/16" - 18 JIC	WIN
15.	129274	[1]	TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC	BHB
16.	101792A1	[1]	COUPLING	CAS Diagnostic
17.	86502604	[1]	DUST CAP	WIN
18.	9617873	[5]	O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro	NH
19.	NSS	[1]	NOT SOLD SEPARAT	CON Manifold, Incl in 7
20.	47604141	[1]	VALVE PRESSURE RELIE	NH 2000 PSI, Incl 25
21.	128359	[1]	O-RING,0.07" Thk x 0.614" ID, -16, Cl 5, 75 Duro	MOD
22.	84559455	[1]	CHECK VALVE	NH -8
23.	235670	[1]	SLEEVE,37 Degree, 3/8" Tube	BEL
24.	136658	[1]	TUBE NUT,0.72" Length	BEL
25.	377451A1	[1]	SEAL KIT	CAS Needle Superseded by part number: 84556584
26.	47765920	[1]	TUBE	PLO
27.	266631	[1]	HYDRAULIC VALVE	PA Check
28.	76344	[1]	90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB	NH
29.	PL	[1]	PROCURE LOCALLY	BAS Tube, Hyd., Incl 23, 24, Start Serial: YGN193203
