凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (35.540.AI[01]) - VAR - 726813 - HYDRAULIC BALE TENSION, DUAL CYLINDERS, MANUAL CONTROL, YGN193203 AND AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
751 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47860096
|
[1] |
HYDRAULIC CYLINDER
|
PLO
Bale Tension, LH
|
| 2. |
84563524
|
[1] |
HYDRAULIC HOSE
|
NH
Rod End
|
| 3. |
84563525
|
[1] |
HYDRAULIC HOSE
|
NH
Base End
|
| 4. |
84563528
|
[1] |
HYDRAULIC HOSE,6.3mm ID x 2794mm L, SAE 100R17
|
NH
Hyd. Guage
|
| 5. |
76350
|
[1] |
HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC
|
NH
Incl 21
|
| 6. |
47482891
|
[1] |
HYDRAULIC MANIFOLD
|
NH
Bale Tension, 2000 PSI
|
| 7. |
47860094
|
[1] |
HYDRAULIC CYLINDER
|
PLO
Bale Tension, RH
|
| 8. |
PL
|
[1] |
PROCURE LOCALLY
|
BAS
Tube, Bale Density, RH, 9.5mm OD x 689mm Long, Incl 22, 23
|
| 9. |
86505972
|
[2] |
BOLT,5/16" - 18 x 2 - 1/4", Gr 5
|
BAS
|
| 10. |
86513020
|
[3] |
TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BEL
Incl 21
|
| 11. |
163335
|
[1] |
TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BEL
Incl 21
|
| 12. |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 13. |
86513049
|
[1] |
PLUG,9/16" - 18 JIC
|
WIN
|
| 14. |
76344
|
[1] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
Incl 21
|
| 15. |
129274
|
[1] |
TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BHB
|
| 16. |
101792A1
|
[1] |
COUPLING
|
CAS
Diagnostic
|
| 17. |
86502604
|
[1] |
DUST CAP
|
WIN
Black
|
| 19. |
266631
|
[1] |
HYDRAULIC VALVE
|
PA
Check
|
| 20. |
574342
|
[1] |
CAP,9/16" - 18 JIC
|
LEC
|
| 21. |
9617873
|
[6] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
|
| 22. |
136658
|
[1] |
TUBE NUT,0.72" Length
|
BEL
|
| 23. |
235670
|
[1] |
SLEEVE,37 Degree, 3/8" Tube
|
BEL
|
