| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 445656A1 | [1] | FAN | BUR550 mm, Reversible; If Equipped Superseded by part number: 47865510, 86566100, 47865490, 86511479 |
| 2. | A184544 | [1] | SPACER | CAS24 mm; Used With Ref 1 |
| 3. | 193425A1 | [4] | FLANGE BOLT,M10 x 1.5 x 50mm | CASM10 x 50; Used With Ref 1 |
| 4. | A173557 | [1] | FAN | CASPusher; If Equipped |
| 6. | 827-10055 | [4] | BOLT,Hex, M10 x 1.5 x 55mm, Cl 10.9 | CASUsed with Ref 4 Superseded by part number: 84437627 |
| 7. | 895-11010 | [4] | WASHER,11mm ID x 20mm OD x 2mm Thk | CASUsed with Ref 4 Superseded by part number: 14496621 |
| 8. | 87452843 | [1] | V-BELT,3.56 mm W x 1714.50 mm L, 8 Ribs | CASEngine Fan and Alternator |
