| 1. | 201-105 | [1] | HYD CONNECTOR,1 7/16"-12 ORFS x 1 5/16"-12 ORB | IH Superseded by part number: 9824055 |
| 2. | 201-129 | [1] | HYD CONNECTOR,1-3/16" - 12 ORFS x 1-5/16" - 12 ORB | CAS Superseded by part number: 87359470 |
| 3. | L11541 | [6] | CABLE TIE,203.2mm L, Nylon | CAS Superseded by part number: 87000312 |
| 4. | 201-407 | [1] | TEE,1 7/16"-12 x 1 5/16"-12 Run, ORFS | IH |
| 5. | 605210R1 | [1] | SPACER,1/2" X-Strng Pipe x 1 1/8" | IH |
| 6. | 430380A1 | [1] | HOSE ASSY. | BURControl Valve To Thermal Bypass Valve |
| 7. | 238-6018 | [2] | O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro | CAS Superseded by part number: 9991976 |
| 8. | 87301279 | [2] | CARRIAGE BOLT,Sht Sq Nk, M10 x 90mm, Cl 8.8 | WIC |
| 9. | 811-12040 | [1] | CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 40mm, Cl 8.8 | CAS Superseded by part number: 328754 |
| 10. | 811-12070 | [1] | CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 70mm, Cl 8.8 | CAS Superseded by part number: 338263 |
| 11. | 832-10410 | [2] | NUT,M10 x 1.5, Cl 8 | CAS Superseded by part number: 190003888452 |
| 12. | 832-10412 | [2] | NUT,M12 x 1.75, Cl 8 | CAS Superseded by part number: 87780366, 412126 |
| 13. | 87655046 | [2] | SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk | BUR |
| 14. | 9840535 | [1] | HYD CONNECTOR,1-3/16" - 12 ORFS x 1-1/16" - 12 ORB | NH Superseded by part number: 87393627 |
| 15. | 82003133 | [3] | SHIELD | BAS |
| 16. | 84289616 | [1] | BY-PASS VALVE | BURThermal Bypass Valve |
| 17. | 84291819 | [1] | HOSE ASSY. | BURFilter To Thermal Bypass Valve |
| 18. | 84298768 | [1] | HOSE ASSY. | BUROil Cooler To Thermal Bypass Valve |
| 19. | 84298769 | [1] | HOSE ASSY. | BURThermal Bypass Valve To Oil Cooler |
| 20. | 86639009 | [2] | CLAMP,63.5mm, Coat, 13.5mm Bolt Hole, P Type | FAR |
| 21. | 9824050 | [3] | O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro | WIN Superseded by part number: 87473574 |
| 22. | 167268 | [3] | O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro | WIN |
| 23. | 9991976 | [2] | O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro | WIN |
| 24. | 167266 | [1] | O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro | NH |
