纽荷兰零件查询(D85B) - CRAWLER DOZER TIER 3 (3/08-) (08-20) - SECTION ASSEMBLY - LIFT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
962 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 87402656 | [1] | HYD VALVE SECTION | BURLift; Incl. Ref 1 - 23 |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONHousing |
| 3. | 211-1007 | [4] | BALL,7/32" Dia | CAS Superseded by part number: 86624942 |
| 4. | 100848A1 | [1] | SPRING | CAS |
| 5. | N7035 | [1] | VALVE POPPET | CAS |
| 6. | S301097 | [1] | SLEEVE VALVE | CAS |
| 7. | 100847A1 | [1] | SLEEVE | CASDetent |
| 8. | 100845A1 | [1] | COLLAR | CASUpper |
| 9. | N7033 | [1] | SEAT | CASLower |
| 10. | 394605A1 | [1] | SPRING | CAS |
| 11. | 100-1162 | [1] | SNAP RING,#62, Ext | CAS Superseded by part number: 515259 |
| 12. | S301093 | [1] | CAP | CAS |
| 13. | D87307 | [1] | VALVE | CASLoad Check; See Figure 08-22 Superseded by part number: 274858 |
| 13A. | 122119A1 | [1] | KIT | CASAnti-Cavitation; See Figure 08-22 |
| . . | 352798A1 | [1] | PACKAGE, REPAIR | CASIncl. Ref 14 - 23 |
| 14. | 357164A1 | [1] | BOOT | CAS |
| 15. | 357163A1 | [1] | RETAINER | CAS |
| 16. | N8194 | [1] | LARGE PLATE | CASPLATE, LARGE |
| 17. | 61-3258 | [2] | HEX SOC SCREW,1/4"-20 x 1/2" | CAS Superseded by part number: 81960 |
| 18. | D88730 | [1] | WASHER,0.77" ID x 1.43" OD | CAS |
| 19. | D88729 | [1] | WASHER,0.76" ID x 1" OD x 0.05" Thk | CAS |
| 20. | 9706714 | [2] | O-RING,0.139" Thk x 0.734" ID, -210, Cl 5, 75 Duro | WINNitrile Rubber |
| 21. | 238-5121 | [1] | O-RING,0.103" Thk x 1.049" ID, -121, Cl 5, 75 Duro | CAS Superseded by part number: 14457980 |
| 22. | 357162A1 | [2] | PLATE | CAS |
| 23. | 61-32514 | [2] | HEX SOC SCREW,1/4"-20 x 7/8" | CAS |
