| 1. |
84370710
|
[1] |
FRAME
|
NH
Pickup, 1.5M Standard
|
| 2. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Slip Clutch
|
| 3. |
47449273
|
[1] |
GUIDE
|
NH
LH
|
| 4. |
47449257
|
[1] |
GUIDE
|
NH
RH
|
| 5. |
84370744
|
[23] |
GUARD
|
NH
|
| 6. |
138820
|
[2] |
FLANGED BEARING
|
GI
Superseded by part number: 86635012
|
| 7. |
86594423
|
[2] |
BEARING,28.6mm Hex x 72mm OD x 25mm W
|
NH
Superseded by part number: 84330069
|
| 8. |
578189
|
[2] |
FLANGE
|
NH
Superseded by part number: 86620026
|
| 9. |
164999
|
[10] |
WASHER
|
NH
|
| 10. |
9804262
|
[15] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 11. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
213404
|
[1] |
SPACER,10.3mm ID x 38.1mm OD x 5.2mm OAL
|
NH
|
| 13. |
87039762
|
[108] |
SELF-TAP SCREW,Hex Wash Hd, 5/16"-18 x 5/8"
|
PA
Superseded by part number: 570821
|
| 14. |
86636761
|
[1] |
CAM
|
NH
Outer
|
| 15. |
47563339
|
[1] |
CAM
|
NH
Inner
|
| 16. |
84539725
|
[1] |
LINK
|
NH
Superseded by part number: 47471603
|
| 17. |
87020910
|
[1] |
SPACER,10.4mm ID x 19mm OD x 8.9mm Thk
|
PA
|
| 18. |
9804277
|
[1] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 19. |
9804260
|
[1] |
BOLT,Hex, M8 x 1.25 x 30mm, Full Thd, Cl 8.8
|
NH
|
| 20. |
88529
|
[2] |
LOCK PIN,5.56mm OD x 44.45mm L, Slotted
|
NH
|
| 22. |
47434872
|
[1] |
CHAIN
|
NH
Inc 30
|
| 23. |
86629541
|
[4] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 24. |
87642988
|
[12] |
WASHER,13.08mm ID x 31.8mm OD x 1.5mm Thk
|
NH
|
| 25. |
9804279
|
[4] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 26. |
300662
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 80mm, Cl 8.8
|
NH
|
| 27. |
87030996
|
[1] |
IDLER
|
NH
|
| 28. |
87613265
|
[5] |
WASHER,0.53" ID x 1.25" OD x 0.13" Thk
|
GI
|
| 29. |
412672
|
[1] |
NUT,Hex, M12 x 1.75, Cl 10
|
WIN
|
| 30. |
84545610
|
[1] |
CONNECTING LINK
|
PLO
|
| 31. |
80707372
|
[1] |
BRACKET
|
NH
Superseded by part number: 86636168
|
| 32. |
100037
|
[1] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 33. |
84333209
|
[4] |
SHIM
|
NH
2.5mm
|
| 34. |
84333207
|
[2] |
SHIM
|
NH
1mm
|
