凯斯零件查询(RB565) - CASE IH ROUND BALER (3/14-12/15) (60.220.BG[02]) - 1.5M STANDARD PICKUP REEL MOUNTING PARTS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
202 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84370710
|
[1] |
FRAME
|
NH
Pickup
|
| 2. |
84472419
|
[1] |
SLIP CLUTCH
|
NH
|
| 3. |
84370725
|
[1] |
GUIDE
|
NH
LH Superseded by part number: 47449273
|
| 4. |
84370737
|
[1] |
GUIDE
|
NH
RH Superseded by part number: 47449257
|
| 5. |
84370744
|
[23] |
GUARD
|
NH
|
| 6. |
138820
|
[2] |
FLANGED BEARING
|
GI
Superseded by part number: 86635012
|
| 7. |
86594423
|
[2] |
BEARING,28.6mm Hex x 72mm OD x 25mm W
|
NH
Superseded by part number: 84330069
|
| 8. |
578189
|
[2] |
FLANGE
|
NH
Superseded by part number: 86620026
|
| 9. |
164999
|
[10] |
WASHER
|
NH
|
| 10. |
9804262
|
[15] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 11. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
88529
|
[2] |
LOCK PIN,5.56mm OD x 44.45mm L, Slotted
|
NH
|
| 13. |
87039762
|
[108] |
SELF-TAP SCREW,Hex Wash Hd, 5/16"-18 x 5/8"
|
PA
Superseded by part number: 570821
|
| 14. |
86636761
|
[1] |
CAM
|
NH
Outer
|
| 15. |
47563339
|
[1] |
CAM
|
NH
Inner
|
| 16. |
84539725
|
[1] |
LINK
|
NH
Superseded by part number: 47471603
|
| 17. |
87020910
|
[1] |
SPACER,10.4mm ID x 19mm OD x 8.9mm Thk
|
PA
|
| 18. |
9804277
|
[1] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 19. |
9671714
|
[1] |
FLANGE BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
