凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (054) - CLUTCH CONTROL, DRIVE SHAFT, ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
470 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700116110
|
[1] |
ANCHOR
|
CAS
MOUNT - magnet (S.N. CFH0016501 thru CFH0017432)
|
| . . |
700122550
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - magnet (S.N. CFH0017432 and on)
|
| 2. |
700116072
|
[4] |
SHIM
|
CAS
- link
|
| 3. |
700116071
|
[3] |
SPACER
|
HFI
|
| 4. |
700116070
|
[4] |
SPACER
|
CAS
|
| 5. |
6212740
|
[1] |
SPACER
|
CAS
|
| 6. |
700116085
|
[1] |
LATCH
|
HFI
(S.N. CFH0016501 thru CFH001683)
|
| 7. |
52183
|
[1] |
BUSHING
|
CAS
3/4 x 18 GAUGE MACHINERY BUSHING (S.N. CFH0016501 thru CFH001683) Superseded by part number: Z52183
|
| 8. |
700707979
|
[1] |
SPRING
|
CAS
- torsion (S.N. CFH0016501 thru CFH001683)
|
| 9. |
700116062
|
[1] |
SPACER
|
CAS
(S.N. CFH0016501 thru CFH001683)
|
| 10. |
700116063
|
[1] |
GUIDE
|
HFI
(S.N. CFH0016501 thru CFH001683)
|
| 11. |
700116066
|
[4] |
ROLLER
|
CAS
ASSEMBLY Superseded by part number: 700126815
|
| 12. |
700116064
|
[4] |
ARM
|
HFI
- clutch
|
| 13. |
700116065
|
[4] |
SPACER
|
HFI
|
| 14. |
700116069
|
[1] |
SPACER
|
HFI
|
| 15. |
700707402
|
[4] |
BEARING, ROLLER, CYL,10 mm ID x 30 mm OD x 9 mm
|
CAS
BEARING - cylindrical Superseded by part number: 9847562
|
| 16. |
700707403
|
[4] |
RING
|
IH
- retainer, internal Superseded by part number: 129738
|
| . . |
703199
|
[3] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
|
CAS
3/8-16 x 3/4 C
|
| . . |
873174
|
[2] |
BOLT,Hex, 3/8" - 16 x 3 1/4", Gr 5
|
CAS
3/8-16 x 3-1/4 C
|
| . . |
701342
|
[2] |
BOLT
|
CAS
3/8-16 x 3-3/4 C Superseded by part number: 413-660
|
| . . |
700702141
|
[1] |
BOLT,Hex, 3/8"-16 x 4 1/4", G5
|
CAS
3/8-16 x 4-1/4 C Superseded by part number: 80280796
|
| . . |
701714
|
[3] |
BOLT,Hex, 3/8" - 16 x 4 1/2", Gr 5
|
CAS
3/8-16 x 4-1/2 C
|
