纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (02-16) - TURBOCHARGER - DRAIN LINE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
562 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852101 | [2] | FLANGE BOLT,Hex, M6 x 16mm | TOR Superseded by part number: 18137825 |
| 2. | 4895107 | [1] | HYD CONNECTOR,11/16"-16 x M12 | TORIncl. Refs. 3, 4 Superseded by part number: |
| 3. | 4899107 | [1] | O-RING,1.8mm Thk x 10.52mm ID | TOR |
| 4. | 4899108 | [2] | O-RING,0.364mm ID x 0.07mm Width | TOR Superseded by part number: 17277981 |
| 5. | 4899467 | [1] | GASKET | TOR |
| 6. | 4899519 | [1] | CLAMP,M16, M6 Bolt | TOR |
| 7. | 4899106 | [1] | HYD CONNECTOR,11/16" - 16 ORFS x M10 x 1.25 ORB | TORIncl. Refs. 4, 11 |
| 8. | 2852195 | [1] | HYDRAULIC HOSE,6.4mm ID x 461mm L | TOROil Supply Superseded by part number: 504053173 |
| 9. | 4899058 | [2] | O-RING,0.674" ID x 0.88" OD x 0.103" | TOR Superseded by part number: 17281881 |
| 10. | 2856979 | [1] | PIPE | TORPIPE, Turbo Drain, Incl. Ref. 9 |
| 12. | 2852197 | [1] | FLANGE NUT,M6 x 1 | TOR Superseded by part number: 17044625 |
| 13. | 2852100 | [1] | FLANGE BOLT,Hex, M8 x 1.25 x 16mm | TOR Superseded by part number: 16586225 |
| 15. | 2830887 | [1] | BRACKET | TOR |
