凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (032) - PICKUP LIFT ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
686 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
296038
|
[2] |
SPECIAL TOOL
|
CAS
Superseded by part number: 380000302, 380000302, 51200240
|
| 2. |
700114185
|
[1] |
CRANK
|
CAS
BELLCRANK - left
|
| 3. |
77032
|
[2] |
FITTING
|
CAS
1/4-28 ZERK Superseded by part number: 88775
|
| 4. |
700114196
|
[2] |
STEM
|
IH
ROD - link
|
| 5. |
066183
|
[4] |
CLEVIS
|
IH
- 1/2-13 thread Superseded by part number: 70937465
|
| 6. |
700114177
|
[1] |
TUBE ASSY.
|
HFI
TUBE ASSEMBLY - torque
|
| 7. |
63966
|
[1] |
PIN
|
CAS
1/2 x clevis pin
|
| 8. |
700114190
|
[1] |
CLEVIS
|
HFI
|
| 9. |
87415
|
[1] |
LUBE NIPPLE,90 Degree, 1/4" NPT x 3/4" L, Drive
|
NH
1/4-28 x 90 deg. ZERK
|
| 10. |
6869382
|
[1] |
SPACER
|
HFI
|
| 11. |
700707873
|
[1] |
THRUST BEARING
|
IH
BEARING - thrust Superseded by part number: 700722820
|
| 12. |
6292387
|
[1] |
SPACER,31.75 mm OD, 44.5 mm Length
|
CAS
|
| 13. |
700114193
|
[1] |
CRANK
|
CAS
ARM - crank
|
| 14. |
700114197
|
[1] |
TUBE,21 mm ID, 25.4 mm OD, 72 mm Length
|
CAS
- crank
|
| 15. |
700114183
|
[1] |
LEVER
|
CAS
ARM - torque, end
|
| 16. |
IH63677
|
[3] |
CLEVIS PIN
|
IH
1/2 x 1-27/64 CLEVIS PIN Superseded by part number: 427-8150
|
| 17. |
52258
|
[2] |
BUSHING
|
CAS
1 x 14 GAUGE MACHINERY BUSHING
|
| 18. |
700114186
|
[1] |
CRANK
|
CAS
BELLCRANK - right
|
| . . |
7701188
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 x 1-1/4 C Superseded by part number: 87670
|
| . . |
702019
|
[1] |
SCREW
|
CAS
3/8-16 x 4 HSHCS Superseded by part number: 61-33864
|
| . . |
9406829
|
[1] |
HEX SOC SCREW,1/2" - 13 x 3 1/2"
|
IH
1/2-13 x 3-1/2 HSHCS
|
