| 1. |
51200382
|
[7] |
BUSHING
|
CAS
1-1/2 x 14 GAUGE MACHINERY BUSHING
|
| 2. |
395871
|
[1] |
SPACER
|
CAS
|
| 3. |
700117122
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - 50-P, 35-tooth
|
| 4. |
38-32436
|
[1] |
PIN,3/8" x 2 1/4", Coiled
|
WIC
3/8" x 2 1/4", Coiled Superseded by part number: 87610718
|
| 5. |
700114135
|
[1] |
DEFLECTOR
|
HFI
- left
|
| 6. |
700114174
|
[1] |
SPACER
|
CAS
|
| 7. |
740712
|
[1] |
OIL SEAL
|
CAS
SNAP RING Superseded by part number: 66967
|
| 8. |
712604
|
[2] |
BALL BEARING,0.7505" ID x 1.7805" OD x 0.61"
|
CAS
BEARING - cylindrical Superseded by part number: 87029275
|
| 9. |
700114166
|
[1] |
PULLEY
|
IH
SHEAVE AND SPROCKET ASSEMBLY
|
| 10. |
700114171
|
[1] |
TUBE,38.1 mm OD, 135.5 mm Length
|
CAS
BUSHING - pivot
|
| 11. |
77032
|
[1] |
FITTING
|
CAS
1/4-28 ZERK Superseded by part number: 88775
|
| 12. |
51417
|
[2] |
PIPE
|
IH
- bearing Superseded by part number: 617863R1, 617863R1, NLS
|
| 13. |
700709621
|
[1] |
SPHERICAL BEARING,31.78mm Hex x 72mm OD x 25mm W
|
CAS
BEARING - spherical, hex bore Superseded by part number: 47442495
|
| 14. |
700114170
|
[2] |
STRAP
|
HFI
- link, pickup
|
| 15. |
378521
|
[1] |
SPACER
|
CAS
BUSHING
|
| 16. |
6610844
|
[1] |
SPACER
|
CAS
|
| 17. |
6156871
|
[1] |
SPACER
|
CAS
|
| 18. |
211623C91
|
[2] |
SPROCKET
|
IH
- idler, 50-P, 17-tooth
|
| 19. |
700114929
|
[1] |
TUBE,31.75 mm OD, 41 mm Length
|
CAS
SPACER
|
| 20. |
700114164
|
[1] |
SHIELD
|
HFI
- chain
|
| 21. |
52712
|
[1] |
BUSHING
|
CAS
1-1/2 x 18 GAUGE MACHINERY BUSHING
|
| . . |
703934
|
[1] |
BOLT,Hex, 5/8" - 11 x 5 1/2", Gr 5
|
CAS
5/8-11 x 5-1/2 C Superseded by part number: 280232, 280232, 87791065
|
| . . |
7883069
|
[1] |
HARDWARE
|
HFI
3/4-10 x 8 C Superseded by part number: 414-12128
|
| . . |
700013
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
700047
|
[3] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
7870603
|
[1] |
BOLT,Sq Nk, 5/8" - 11 x 5 1/2", Gr 5
|
CAS
5/8-11 x 5-1/2 RHSNB
|
| . . |
7883325
|
[1] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
703132
|
[1] |
SERRATED SCREW
|
CAS
5/16-18 x 3/4 HFSS Superseded by part number: 145913
|
