纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (02-28A) - DYNAMIC BALANCER, GEARS & SHAFTS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
802 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2855744 | [1] | HOUSING | TORIncl. Refs. 1 - 8 |
| 1. | 2831305 | [1] | DOWEL,M8 x 17 L | TOR |
| 2. | 4899027 | [2] | DOWEL,M14.05 x 14 L | TOR |
| 3. | 2830948 | [1] | IDLE SHAFT | TOR |
| 4. | 2855746 | [1] | THRUST PLATE | TOR |
| 5. | 2831303 | [1] | HOUSING | TOR |
| 6. | 2831302 | [1] | HOUSING | TORIncl. Ref. 7 |
| 7. | 4891209 | [6] | DOWEL,M13 x 8 L | TOR |
| 8. | 4895323 | [12] | FLANGE BOLT,Hex, M8 x 1.25 x 40mm | LEC |
