| 1. |
700709152
|
[1] |
TERMINAL BOX
|
CAS
AUTO SEQUENCE BOX ASSEMBLY Superseded by part number: 700125030
|
| 2. |
700708763
|
[1] |
HARNESS
|
CAS
- wiring
|
| 3. |
751487
|
[4] |
CLAMP
|
CAS
- wiring Superseded by part number: 86632595
|
| 4. |
86624005
|
[2] |
CLAMP,19mm, Coat, 10.3mm Bolt Hole, P Type
|
FOR
- wiring
|
| 5. |
722470
|
[1] |
MOUNTING CLIP
|
CAS
CABLE TIE Superseded by part number: 529070
|
| 6. |
700119161
|
[1] |
SWITCH
|
L
SENSOR "A"
|
| 7. |
529070
|
[2] |
CABLE TIE,368.3mm L
|
NH
CABLE TIE
|
| 8. |
700120657
|
[1] |
ORNAMENTAL STRIP
|
HFI
GROMMET - rubber
|
| 9. |
700708340
|
[1] |
GROMMET
|
CAS
- rubber
|
| 10. |
700708090
|
[11] |
CLAMP
|
L
- wiring Superseded by part number: 86637978
|
| 11. |
8025637
|
[2] |
SWITCH
|
L
|
| 12. |
7827983
|
[3] |
GROMMET
|
CAS
- rubber
|
| 13. |
700705710
|
[1] |
FUSE
|
HFI
(3 amp) Superseded by part number: 86503942
|
| 14. |
700707354
|
[1] |
CONNECTION,ELECTRIC
|
IH
ACTUATOR - round
|
| . . |
703199
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
|
CAS
3/8-16 x 1 C
|
| . . |
702035
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 x 1-1/4 C
|
| . . |
7883275
|
[2] |
SCREW,Hex Washer, 1/4" - 20 x 3/4"
|
CAS
1/4-20 x 3/4 HWHMS
|
| . . |
7883325
|
[9] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
7883333
|
[1] |
BOLT,Hex, 5/16" - 18 x 1", Gr 120M
|
CAS
5/16-18 x 1 HWHMS Superseded by part number: 121-108
|
| . . |
7883374
|
[1] |
SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 x 3/4 HWHMS Superseded by part number: 255918
|
| . . |
7883382
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 x 1 HWHMS Superseded by part number: 87034804
|
| . . |
701953
|
[5] |
SELF-TAP SCREW
|
CAS
5/16-18 x 3/4 HWHTCTS Superseded by part number: 172463
|
| . . |
704726
|
[4] |
LOCK NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN Superseded by part number: 232-5315
|
