| 1. |
7016
|
[2] |
1/4-28 ZERK
|
|
| 2. |
77057
|
[1] |
|
IH
1/4-28 x 90 deg. ZERK Superseded by part number: 87415, 87415, NLS
|
| 3. |
700116177
|
[1] |
SUPPORT
|
HFI
plate
|
| 4. |
47977
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - idler, 40-P Superseded by part number: 103243
|
| 5. |
700116091
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - pump
|
| 6. |
700116094
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - switch
|
| 7. |
700116093
|
[1] |
STOP
|
HFI
|
| 8. |
700117086
|
[1] |
STRAP
|
HFI
|
| 9. |
700116096
|
[1] |
LEVER ASSY.
|
HFI
LEVER
|
| 10. |
700707432
|
[2] |
SPRING
|
L
|
| 11. |
700116098
|
[1] |
LATCH
|
HFI
|
| 12. |
700117105
|
[1] |
SHIELD
|
HFI
|
| 13. |
6143358
|
[1] |
BUSHING
|
HFI
SPACER Superseded by part number: 50061K
|
| 14. |
700116190
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - pump, 40-P, 15-tooth
|
| 15. |
700116092
|
[1] |
SUPPORT
|
HFI
- spring
|
| 16. |
700116101
|
[1] |
LATCH
|
HFI
|
| 17. |
700116100
|
[1] |
PLATE
|
HFI
|
| 18. |
700116106
|
[4] |
SPACER
|
HFI
|
| 19. |
700116105
|
[1] |
LINK
|
HFI
|
| 20. |
700116107
|
[1] |
PLATE
|
HFI
|
| 21. |
700707710
|
[1] |
CHAIN (AG)
|
CAS
R/C 40 ROLLER CHAIN (with o-rings)
|
| 22. |
700708338
|
[1] |
LINK
|
CAS
R/C 40 connector link (with o-rings)
|
| 23. |
740512
|
[1] |
- oilite
|
BUSHING
|
| . . |
7773914
|
[1] |
BOLT,Hex, 5/16" - 24 x 3/4", Gr 5
|
CAS
5/16-24 x 3/4 C Superseded by part number: 114-101
|
| . . |
413-58
|
[1] |
BOLT,Hex, 5/16" - 18 x 1/2", Gr 5
|
CAS
5/16-18 x 1/2 C Superseded by part number: 72187203, 88574
|
| . . |
7701717
|
[1] |
BOLT,Hex, 5/16" - 18 x 1 1/2", Gr 5
|
CAS
5/16-18 x 1-1/2 C Superseded by part number: 88275
|
| . . |
703249
|
[5] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
701235
|
[4] |
BOLT,1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 x 1-1/2 C
|
| . . |
873083
|
[4] |
SCREW
|
CAS
3/8-16 x 1-1/2 FTHCS
|
| . . |
7870199
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2 3/4", Gr 5
|
CAS
5/8-11 x 2-3/4 RHSNB Superseded by part number: 9602228
|
| . . |
61-33828
|
[1] |
HEX SOC SCREW,3/8"-16 x 1 3/4"
|
CAS
3/8-16 x 1-3/4 HSHCS Superseded by part number: 86511683
|
| . . |
7883382
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 x 1 HWHMS Superseded by part number: 87034804
|
| . . |
7771363
|
[4] |
BOLT,Hex Flange, 1/2" - 13 x 1 1/4", SPL
|
CAS
1/2-13 x 1-1/4 HFSS Superseded by part number: 84209
|
| . . |
230-4215
|
[2] |
NUT,5/16"-18, GA
|
CAS
5/16-18 HCLN
|
| . . |
704635
|
[1] |
NUT
|
CAS
3/8-16 HCLN Superseded by part number: 230-4216, 230-4216, 88902
|
