| 1. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 2. |
87415
|
[1] |
LUBE NIPPLE,90 Degree, 1/4" NPT x 3/4" L, Drive
|
NH
1/4-28 x 90 deg. ZERK
|
| 3. |
700116177
|
[1] |
SUPPORT
|
HFI
plate
|
| 4. |
700116107
|
[1] |
PLATE
|
HFI
(S.N. CFH0016839 thru CFH0017432)
|
| . . |
700122565
|
[1] |
PLATE
|
HFI
(S.N. CFH 0017433 and on) mating part for 700122555 mounting - actuator Superseded by part number: 700125072
|
| 5. |
47977
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - idler, 40-P Superseded by part number: 103243
|
| 6. |
700119133
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - pump
|
| 7. |
700117086
|
[1] |
STRAP
|
HFI
|
| 8. |
700116094
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - switch
|
| 9. |
700119717
|
[1] |
MOUNTING PARTS
|
HFI
MOUNTING - switch
|
| 10. |
700118822
|
[1] |
SPACER
|
CAS
|
| 11. |
700708998
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - pump 40-P, 17 tooth
|
| 12. |
700707710
|
[1] |
CHAIN (AG)
|
CAS
R/C 40 roller chain (with o-rings)
|
| 13. |
700708338
|
[1] |
LINK
|
CAS
R/C 40 connector link (with o-rings)
|
| 14. |
740512
|
[1] |
- oilite
|
BUSHING
|
| 15. |
700122555
|
[1] |
MOUNTING PARTS
|
HFI
MOUNTING - actuator (S.N. CFH0017433 and on) mating part for the 700122565 plate
|
| 16. |
52175
|
[1] |
BUSHING,25.48mm ID x 38.2mm OD x 3.17mm L
|
CAS
5/8 x 18 GAUGE MACHINERY BUSHING
|
| . . |
7703457
|
[1] |
HYD CONNECTOR,Hex, 1/4" - 20 x 3/4", Gr 5
|
NNA
1/4-20 x 3/4 C Superseded by part number: 413-412, 413-412, 86516954
|
| . . |
7773914
|
[1] |
BOLT,Hex, 5/16" - 24 x 3/4", Gr 5
|
CAS
5/16-24 x 3/4 C Superseded by part number: 114-101
|
| . . |
703199
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd
|
CAS
3/8-16 x 3/4 C
|
| . . |
701235
|
[4] |
BOLT,1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 x 1-1/2 C
|
| . . |
7870173
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2 1/4", Gr 5
|
CAS
5/8-11 x 2-1/4 RHSNB Superseded by part number: 111-622
|
| . . |
7771363
|
[4] |
BOLT,Hex Flange, 1/2" - 13 x 1 1/4", SPL
|
CAS
1/2-13 x 1-1/4 HFSS Superseded by part number: 84209
|
| . . |
88902
|
[1] |
NUT,3/8"-16
|
NH
3/8-16 HCLN
|
| . . |
73213
|
[1] |
SCREW
|
CAS
3/8-16 x 1-3/4 HSHCS Superseded by part number: 61-33828, 61-33828, NLS
|
| . . |
71142
|
[1] |
HEX SOC SCREW,1/2"-13 x 2"
|
IH
1/2-13 x 2 HWHMS Superseded by part number: 86570628
|
