纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (02-39) - COOLING SYSTEM - ENGINE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
865 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899109 | [3] | SCREW,Hex, M10 x 1.5 x 80 | BAS |
| 2. | 2854072 | [1] | SEALING RING,Square, 5.16mm Thk x 50.17mm ID | TOR Superseded by part number: 504062710 |
| 3. | 2855776 | [1] | SUPPORT | TORIncl. Ref. 4 |
| 4. | 2830894 | [2] | DOWEL,.25" OD x .625" L | TORNot Illustrated |
| 5. | 2852511 | [1] | PLUG | TORThreaded Superseded by part number: 504074178 |
| 6. | 4895623 | [1] | HEX SOCKET PLUG,M16 x 1.5 | TORCompressor Coolant Plumbing, Not Illustrated |
| 7. | 4893036 | [1] | PIPE PLUG,3/4"-14 NPTF | TORCompressor Coolant Plumbing, Not Illustrated Superseded by part number: 2854866 |
