纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (02-40) - THERMOSTAT - ENGINE COOLING SYSTEM New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
989 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899110 | [3] | SCREW,Hex Flg, M6 x 1 x 20 | TOR |
| 2. | 4895131 | [1] | HOUSING | TOR Superseded by part number: |
| 3. | 2856543 | [1] | THERMOSTAT | TORASSY. Incl. Ref. 4 Superseded by part number: 84322388 |
| 4. | 2852473 | [1] | GASKET,53.62mm ID x 59.72mm OD x 4.01mm Thk | TOR |
| 5. | 4893036 | [1] | PIPE PLUG,3/4"-14 NPTF | TORAlternate part Superseded by part number: 2854866 |
| 5. | 2854866 | [1] | HEX SOCKET PLUG,3/4"-14 NPTF | TORAlternate part Superseded by part number: 4893036 |
| 6. | 4895078 | [4] | PIPE PLUG,1/2"-14 | TOR |
| 7. | 2854491 | [1] | PLUG,Taper Pipe, Hex, 1/4" - 18 x 14.224mm | TOREngine Coolant Vent, Not Illustrated |
