纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (01-02) - KIT, SAND SCREEN New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
600 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 47807364 | [1] | KIT | BURSand Screen, Incl 2 - 6 |
| 2. | 14496621 | [4] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | TTF |
| 3. | 43252 | [4] | BOLT,Hex, M10 x 1.5 x 80mm, Cl 10.9 | GI |
| 4. | 47799887 | [1] | DUST SCREEN | BURSand, Painted |
| 5. | 87655046 | [4] | SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk | BUR |
| 6. | 9861444 | [4] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9 | BHB Superseded by part number: 11106031 |
