纽荷兰零件查询(D95B) - CRAWLER DOZER TIER 3 (3/08-) (03-07) - FUEL INJECTION SYSTEM - INJECTOR New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
230 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4895483 | [8] | BOLT,Flng, M6 x 1 x 35mm | TORM6 x 35 |
| 2. | 2854606 | [4] | FUEL TUBE,Connector Assembly | SMASSY. Incl. Ref. 3 |
| 3. | 4890929 | [1] | O-RING,3mm Thk x 11mm ID | TOR |
| 4. | 4893739 | [4] | TUBE NUT | TOR |
| 5. | 2855491 | [4] | FUEL SYSTEM INJECTOR | TORIncl. Refs. 5A, 5B, 6 |
| 5. | 2855491R | [4] | REMAN-INJECT NOZZLE | RACREMAN-INJECTION NOZZLE Injector Nozzle; |
| 5. | 2855491C | [4] | CORE-NOZZLE, INJECT | RACReturn Number |
| 5A. | 4899689 | [1] | SEALING WASHER,7mm ID x 15mm OD x 1.5mm Thk | TOR |
| 5B. | 4890926 | [1] | O-RING,3mm Thk x 20.9mm ID, 60 Duro | TOR20.9 ID x 3.0 DIA |
| 6. | 2854609 | [1] | BRACKET | TORRetainer Superseded by part number: 504091492 |
