| 1. | 87351690 | [1] | HOSE,38.10 mm ID x 849.00 mm, SAE 100R4 | BUR849 mm (33-7/16 in) Length Hose; Supply From Tank |
| 2. | 214-2130 | [2] | CLAMP,#30, 1.81"-2.06", T-Bolt | CAS Superseded by part number: 71404506 |
| 3. | 217-327 | [1] | FITTING,45º, 1 1/2" Hose x 1 5/8"-12 ORB Beaded | BRRIncl. Ref 4 |
| 4. | 237-6020 | [1] | O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro | CAS Superseded by part number: 87779389, 570186 |
| 5. | 418237A1 | [1] | FILTER ASSY | BURSee Figure 06-09 |
| 6. | 614-10020 | [4] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd | CAS Superseded by part number: 43138 |
| 7. | 895-11010 | [4] | WASHER,11mm ID x 20mm OD x 2mm Thk | CAS Superseded by part number: 14496621 |
| 8. | 201-327 | [1] | ELBOW,90º, 13/16"-16 x 1 1/16"-12, Adj, ORFS | CASIncl. Ref 9, 10 Superseded by part number: 87591918 |
| 9. | 238-6014 | [1] | O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9992298 |
| 10. | 237-6012 | [1] | O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro | CASBoss End Superseded by part number: 72186120, 167266, 79051113 |
| 11. | 435014A1 | [1] | HOSE ASSY. | BUR252 mm (9-15/16 in); Filter To Tank; Charge Filter Bypass |
| 12. | 201-128 | [1] | HYD CONNECTOR,13/16"-16 ORFS x 1 1/16"-12 ORB | CASIncl. Ref 13, 14 |
| 15. | A166057 | [1] | TEMPERATURE SENDER | CASTransmission Oil Temperature Superseded by part number: 84300765 |
| 16. | 201-307 | [2] | ELBOW,90º, 1 3/16"-12 x 1 1/16"-12 Adj, ORFS | CASIncl. Ref 17, 18 Superseded by part number: 9846848 |
| 17. | 238-6018 | [1] | O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9991976 |
| 19. | 87606636 | [1] | HOSE ASSY., 1828 mm (72 in); Filter Outlet To Hydrostatic Pump | |
| . . | 87313817 | [1] | CONDUIT | BUR1-1/4 ID, Used On 430511A1 Hose, If Used |
| . . | L18331 | [2] | CABLE TIE,375.9mm L | CASUsed On 87313817 Sleeve If Used Superseded by part number: 529070 |
| 20. | 201-419 | [1] | TEE,1 3/16"-12 ORFS x 1 3/16"-18 Sw Br | CASIncl. Ref 21 |
| 22. | 201-141 | [2] | HYD CONNECTOR,1 3/16"-12 ORFS x 3/4"-16 ORB | CASIncl. Ref 23, 24 |
| 23. | 237-6008 | [1] | O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro | CASBoss end Superseded by part number: 128825 |
| 25. | 430512A2 | [1] | HOSE ASSY. | BUR980 mm (38-5/8 in); Filter Outlet Crossover |
| 26. | 201-104 | [1] | HYD CONNECTOR,1-3/16" - 12 ORFS x 1-1/16" - 12 ORB | CASIncludes Ref. 27, 28 Superseded by part number: 87393627 |
| 29. | 429711A1 | [1] | HOSE ASSY. | BUR335 mm (13-1/4 in); Case Drain |
| 30. | 201-428 | [1] | TEE,1-3/16" - 12 ORFS x 1-3/16" - 12 ORFS x 1-1/16" - 12 ORB | CASIncl. Ref 31, 32 |
| 33. | 429712A1 | [1] | HOSE ASSY. | BUR975 mm (38-7/16 in); Case Drain To Tank |
| 34. | 447886A1 | [1] | TEE | BURIncl. Ref 35, 36 |
| 37. | 201-147 | [1] | REDUCER,1 3/16"-12 Male x 1 7/16"-12 Fem, ORFS | CASIncl. Ref 38 |
| 39. | 86988878 | [1] | VALVE, CHECK | BUR1 ORFS x 1 ORB; To Tank; Incl. Ref 40, 41 |
| 40. | 237-6016 | [1] | O-RING,0.116" Thk x 1.171" ID, -916, Cl 6, 90 Duro | CASBoss End Superseded by part number: 72186238, 167268 |
| 41. | 238-6021 | [1] | O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 87473574 |
| 42. | 430510A1 | [1] | HOSE ASSY. | BUR1730 mm (68-1/8 in); Filter Inlet |
| 43. | 201-103 | [1] | HYD CONNECTOR,1"-14 ORFS x 7/8"-14 ORB | CASIncludes Ref 44, 45 Superseded by part number: 83963000 |
| 44. | 237-6010 | [1] | O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro | CASBoss End Superseded by part number: 72186125, 167269 |
| 45. | 238-6016 | [1] | O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro | CASFace Seal End Superseded by part number: 9992069 |
| 46. | 242999A1 | [3] | CLAMP | CASDouble Clamp |
| 47. | 515-25317 | [1] | CLAMP,1 1/4", Insul, 1/2" Bolt | CAS |
| 49. | 811-12050 | [1] | CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 50mm, Cl 8.8 | CAS Superseded by part number: 334682 |
| 50. | 832-10412 | [2] | NUT,M12 x 1.75, Cl 8 | CAS Superseded by part number: 87780366, 412126 |
| 51. | 811-12070 | [1] | CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 70mm, Cl 8.8 | CAS Superseded by part number: 338263 |
| 52. | 487704R1 | [1] | SPACER,3/4" Tube x 1 3/16" | IH |
| 55. | 201-124 | [1] | REDUCER,1"-14 Male x 1 3/16"-16 Fem, ORFS | IHIncl. Ref. 56 Superseded by part number: 84989617 |
