凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (016) - HITCH AND JACK ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
533 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700706826
|
[1] |
JACK
|
IH
(includes pin and chain)
|
| 2. |
700706640
|
[1] |
PIN
|
L
AND CHAIN
|
| 3. |
63768
|
[1] |
PIN
|
CAS
AND CHAIN - linch
|
| 4. |
700114468
|
[2] |
WASHER,26.19mm ID x 63.5mm OD x 6mm Thk
|
IH
- special
|
| 5. |
700114175
|
[1] |
PIN
|
CAS
- hitch Superseded by part number: 700125679
|
| 6. |
6227391
|
[1] |
TUBE,2" OD, 1.88" Length
|
CAS
- Weldment
|
| . . |
704973
|
[1] |
SLOTTED NUT,1"-8, G5
|
CAS
1-8 SHN Superseded by part number: 87343900
|
| . . |
705681
|
[4] |
WASHER,1", SAE
|
CAS
1 NP Superseded by part number: 87367
|
