凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (068) - INDICATOR, BALE SIZE, ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
270 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700115976
|
[1] |
INDICATOR
|
HFI
|
| 2. |
700115973
|
[3] |
SPACER
|
CAS
|
| 3. |
700115983
|
[1] |
ANGLE
|
HFI
|
| 4. |
700115988
|
[1] |
LINK ASSY.
|
HFI
LINK - indicator
|
| 5. |
700115982
|
[1] |
SUPPORT
|
HFI
ARM
|
| 6. |
1713155
|
[1] |
FLAP
|
CAS
- counter
|
| 7. |
700707234
|
[1] |
BUTTON
|
IH
KNOB
|
| 8. |
700115974
|
[1] |
SUPPORT
|
HFI
- switch
|
| . . |
703579
|
[1] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5, Full Thd
|
CAS
5/16-18 x 1 C
|
| . . |
703249
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
700013
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
7701188
|
[1] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 x 1-1/4 C Superseded by part number: 87670
|
| . . |
7883325
|
[6] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
704619
|
[1] |
SUPPORT
|
NNA
5/16-18 HCLN Superseded by part number: 230-4215
|
