凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (066) - SHIELDS, UPPER SIDE, ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
847 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700117052
|
[1] |
SHIELD
|
CAS
- left
|
| 2. |
700117061
|
[2] |
LATCH
|
CAS
- detent
|
| 3. |
63784
|
[4] |
CLEVIS PIN
|
IH
1/4 x 1-1/2 CLEVIS PIN Superseded by part number: 141-13
|
| 4. |
776674
|
[4] |
SUPPORT
|
L
BASE - anchor
|
| 5. |
776682
|
[4] |
HOOK
|
CAS
- rubber Superseded by part number: 86975220
|
| 6. |
700117066
|
[2] |
CHANNEL
|
CAS
- reinforcement
|
| 7. |
754606
|
[2] |
SPRING
|
CAS
- compression
|
| 8. |
700117058
|
[2] |
SUPPORT
|
CAS
- pin
|
| 9. |
700117062
|
[1] |
SHIELD
|
CAS
- right
|
| 10. |
763565
|
[2] |
PIN
|
CAS
5/16 x 2 clevis pin Superseded by part number: 439-5532
|
| 11. |
700707701
|
[4] |
HINGE
|
CAS
- butt
|
| 12. |
700117067
|
[2] |
SUPPORT
|
CAS
ROD - detent
|
| 13. |
S120261
|
[2] |
PIN
|
CAS
HAIRPIN COTTER
|
| . . |
7883325
|
[29] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
705608
|
[2] |
WASHER,5/16", SAE
|
CAS
5/16 NP Superseded by part number: 495-11034
|
