| 1. |
700707665
|
[2] |
LARGE PLATE
|
IH
LEAF - spring
|
| 2. |
700107980
|
[1] |
ARM
|
CAS
- threader, twine
|
| 3. |
700115955
|
[1] |
SHAFT
|
HFI
JACKSHAFT - gear
|
| 4. |
740159
|
[2] |
RING, SNAP
|
CAS
RING - retainer Superseded by part number: 25121
|
| 5. |
700107978
|
[1] |
PLATE
|
HFI
|
| 6. |
700107977
|
[2] |
GUIDE
|
CAS
- twine
|
| 7. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 8. |
52266
|
[4] |
WASHER
|
CAS
1-1/4 x 14 GAUGE MACHINERY BUSHING Superseded by part number: 495-81205
|
| 9. |
52613
|
[2] |
RING, SNAP
|
CAS
RING - retainer Superseded by part number: 103-11125
|
| 10. |
700107974
|
[1] |
INDICATOR
|
HFI
- threader arm
|
| 11. |
6549869
|
[2] |
SUPPORT
|
L
BRACKET - tension
|
| 12. |
700107969
|
[1] |
PLATE
|
HFI
SUPPORT - pulley, twine
|
| 13. |
6869382
|
[1] |
SPACER
|
HFI
|
| 14. |
700116222
|
[1] |
PULLEY ASSY.
|
HFI
PULLEY - feeder, twine
|
| 15. |
700707677
|
[2] |
SPRING
|
L
- compression
|
| 16. |
7745003
|
[1] |
GUIDE
|
L
- twine
|
| 17. |
51200861
|
[1] |
U-BOLT
|
BRR
5/16-18 thread
|
| 18. |
214-1406
|
[2] |
HOSE CLAMP,#06, 0.44" - 0.78", Type F Worm
|
CAS
CLAMP - hose Superseded by part number: 244358
|
| 19. |
700707201
|
[1] |
HOSE
|
CAS
- flex
|
| 20. |
700707402
|
[1] |
BEARING, ROLLER, CYL,10 mm ID x 30 mm OD x 9 mm
|
CAS
BEARING - cylindrical Superseded by part number: 9847562
|
| 21. |
740514
|
[2] |
BUSHING,31.81mm ID x 38.2mm OD x 50.8mm L
|
L
- oilite
|
| 22. |
700707403
|
[1] |
RING
|
IH
- retainer Superseded by part number: 129738
|
| 23. |
7751605
|
[1] |
BREATHER
|
CAS
VENT - breather Superseded by part number: 219-433
|
| 24. |
846642
|
[1] |
BUSHING
|
CAS
- reducer
|
| 25. |
858183
|
[1] |
SPRING
|
CAS
- compression, S.N. CFH0017639 and on
|
| 26. |
700122575
|
[1] |
BUTTON
|
CAS
- nylon, S.N. CFH 0017639 and on
|
| . . |
700707343
|
[2] |
SCREW
|
CAS
1/4-20 x 5/8 C Superseded by part number: 280641
|
| . . |
7773856
|
[2] |
BOLT,Hex, 1/4" - 20 x 2 3/4", Gr 5
|
CAS
1/4-20 x 2-3/4 C Superseded by part number: 280566
|
| . . |
413-520
|
[1] |
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
|
CAS
5/16-18 x 1-1/4 C (shear bolt) Superseded by part number: 87657
|
| . . |
703249
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| . . |
7701055
|
[1] |
LEVER,Hex, 3/8" - 16 x 1 3/4", Gr 5
|
NNA
3/8-16 x 1-3/4 C Superseded by part number: 413-628, 413-628, NLS
|
| . . |
700864
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2 1/4", Gr 5
|
CAS
3/8-16 x 2-1/4 RHSNB Superseded by part number: 280514
|
| . . |
7883325
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
704783
|
[4] |
SHIM,.020" Thk
|
NNA
1/4-20 HCLN Superseded by part number: 230-4214
|
| . . |
230-4215
|
[3] |
NUT,5/16"-18, GA
|
CAS
5/16-18 HCLN
|
