凯斯零件查询(8460) - CASE IH ROUND BALER (BEFORE S/N CFH0057418) (1/88-12/93) (080) - BALE TENSION ROLLERS ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
885 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700100927
|
[2] |
HUB
|
L
- roller
|
| 2. |
700118652
|
[2] |
WASHER
|
CAS
- wear
|
| 3. |
8050825
|
[6] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- cylindrical Superseded by part number: F82059
|
| 4. |
700118645
|
[1] |
ROLLER
|
CAS
ASSEMBLY WITH SHAFT Superseded by part number: 700124616
|
| 5. |
700114356
|
[1] |
ARM/LIFTING DEVICE
|
HFI
ARM - tension, lower
|
| 6. |
700107957
|
[2] |
CLAMP
|
HFI
- half
|
| 7. |
700118648
|
[1] |
SHAFT
|
HFI
- roller
|
| 8. |
87569
|
[4] |
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
|
PA
1/4-28 x 45 deg. ZERK
|
| 9. |
6520233
|
[8] |
BUSHING
|
HFI
|
| 10. |
700118536
|
[6] |
SHIM
|
HFI
|
| 11. |
6864607
|
[1] |
ROLLER
|
CAS
- idler with bearing Superseded by part number: 700124615
|
| . . |
61-34424
|
[8] |
HEX SOC SCREW,7/16"-14 x 1 1/2"
|
CAS
7/16-14 x 1-1/2 HSHCS Superseded by part number: 280281
|
| . . |
700707981
|
[4] |
SCREW,FLAT, 3/4" - 10 x 1-3/4"
|
L
3/4-10 x 1-3/4 HSFCHCS
|
